Name: 60095-HD Digital High Temperature MOR Machine for Refractory Testing
Brand: Hai Da Labtester
SKU: 60095-HD
Price: 4,000.00 USD
Availability: InStock

60095-HD Digital High Temperature MOR Machine for Refractory Testing

$60095-HD Digital High Temperature MOR Machine for Refractory Testing$ $60095-HD Digital High Temperature MOR Machine for Refractory Testing$

$60095-HD Digital High Temperature MOR Machine for Refractory Testing$

Большие изображения : 60095-HD Digital High Temperature MOR Machine for Refractory Testing

Подробная информация о продукте:

Place of Origin:	Guangdong, China (Mainland)
Фирменное наименование:	Haida
Сертификация:	ISO,CE
Model Number:	60095-HD

Оплата и доставка Условия:

Minimum Order Quantity:	1 Set
Цена:	лично переговорить
Packaging Details:	Export wooden case
Delivery Time:	15 days after order confirmed
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	30 Sets per Month Haida

контакт

60095-HD Digital High Temperature MOR Machine for Refractory Testing

описание

Display Device:	PC	All Weight:	2800kg
Available Tensile Stroke:	900mm	Unit Switchover:	G, KG, N, LB
Weight:	500 kg	Test Speed:	0.1~300mm/min
Usage:	Tension Material Tension Strength Tester	Resolution:	1/100,000
Test Space Height:	500 mm	Crosshead Travel:	1000 mm
Force Reading:	kgf, Ibf, N, KN, T etc	Load Capacity:	5-200kg
Crosshead Speed Accuracy:	±0.2%	Grip:	Tensile grip, Tear force grip
Dimensions:	1200 mm x 800 mm x 1800 mm
Выделить:	200kg Load Capacity MOR Machine , Refractory Testing High Temperature MOR Machine , Digital High Temperature MOR Machine

60095-HD Digital High Temperature MOR Machine

Product Specifications

Attribute	Value
Display Device	PC
All Weight	2800kg
Available Tensile Stroke	900mm
Unit Switchover	G, KG, N, LB
Weight	500 kg
Test Speed	0.1~300mm/min
Usage	Tension Material Tension Strength Tester
Resolution	1/100,000
Test Space Height	500 mm
Crosshead Travel	1000 mm
Force Reading	kgf, Ibf, N, KN, T etc
Load Capacity	5-200kg
Crosshead Speed Accuracy	±0.2%
Grip	Tensile grip, Tear force grip
Dimensions	1200 mm x 800 mm x 1800 mm

Product Description

The 60095-HD Digital High Temperature MOR Machine is designed for testing high temperature flexural strength of various materials including refractory products, carbon-containing refractory materials, dense refractory castables, ceramic rollers, and other ceramics. Compliant with multiple industry standards including GB3002-2017, GB/T13243-1991, YB/T 5201-93, JB/T 2980.2-1999, and HB/T 5352.1-2004.

Computer-connected for automatic testing and data processing
Simple structure with stable force application and easy maintenance
Maximum temperature options: 1400℃ or 1600℃
Maximum load options: 1000N, 10000N, or 20000N
Temperature control accuracy: ±1℃
Automatic sample feeding mechanism for continuous testing
Can test 4-6 samples simultaneously
Voltage: 380V with power options of 8KW or 12KW
Heating elements: silicon carbon rod (1400℃) or silicon molybdenum rod (1600℃)
Generates test reports with print output capability

Standard Sample Sizes
